Garden
RenderFootprint 6,3 × 1,2 m (+ parallettes)
Station 6 Flagship
Full Station (All-in-One)
Everything in one rig: wall bars, rings, hangboard, dips and every bar height.
The everything-in-one rig, built as one 6,3 m line. Still only posts, pipe, one beam and bolts.
Details
What's included
- Wall bars: 5 rungs about 40 cm apart plus a 48 mm fat-grip top rung at 2,30 m
- 1,50 m wide-grip and muscle-up bar at 2,35 m
- Bengkirai suspension beam (1,50 m clear) with 5 rated eye bolts every 30 cm for rings, a suspension trainer, bands or a dip belt
- Wooden gym rings with straps
- Hardwood hangboard across the top of the wall bars (jug rail, edges, pockets)
- Mid bar 1,70 m, row bar 0,95 m and low foot-anchor bar 0,20 m
- Tapered V dips (48 → 68 cm) for narrow and broad shoulders
- Pair of parallettes
- Installation and load tests
Size
- Wall bars
- 0,80 m clear; 1" rungs at 0,35 / 0,75 / 1,15 / 1,55 / 1,95 m + 48 mm fat-grip rung at 2,30 m
- Muscle-up bar
- 2,35 m, 1,50 m clear
- Suspension beam
- bengkirai 12×16 cm, underside 2,59 m, 1,50 m clear; 5 eye bolts at 30 cm
- Hangboard
- 104 × 16 cm, 65 cm grip zone, edges at ≈ 2,50–2,62 m; reach from the 0,35 m rung
- Mid, row and anchor bars
- 1,70 m, 0,95 m and 0,20 m; 1,20 m clear
- V dips
- 1,25 m high, 1,00 m long, 48 → 68 cm
- Footprint
- 6,3 × 1,2 m (+ parallettes)
- Free zone
- 8,5 × 4,0 m
- Footings
- 8 × 40×40×70 cm
